Let’s talk about domain names. Despite being a strictly digital creation, they are intertwined with the social and political complexities of the real world.

Domain Structure

In the beginning, there were six top-level domains (TLDs):

  • .com
  • .net
  • .org
  • .edu
  • .mil
  • .gov

Wait, what is a top-level domain? Let’s back up and talk about the parts of a domain name. As an example, let’s use the domain for this site: blog.nathanv.me.

blog.nathanv.me has 3 parts, seperated by 2 dots (more on that in a second). From right-to-left:

  • me: This is referred to as the top-level domain
  • nathanv: This is the second-level domain, often referred to as just the “domain” or “root domain”
  • blog: This is known as the subdomain

Notice how we went right-to-left? While English speakers read left-to-right, domain names are actually heirarchical, with each segment becoming more specific as you move left 1. So for blog.nathanv.me, the name blog is a subdomain of nathanv, which is a subdomain of the Montegro registry me.

As there are dots seperating the parts of a domain name, there is actually an implied dot at the end of any domain name, as the top-level domain me is actually a child of the DNS root .. So, you can write blog.nathanv.me. and it will still work just the same. Try it in your browser! Usually this is left off as us pesky humans are lazy when the last character of a domain name is always the same.

History

So, back to top-level domains. On January 1st 1985, the DNS (Domain Name System) was born. The history is complicated, and Wikipedia goes into great detail about it, but the short version is that six original top-level domains were created. These were: .com meant for companies, .net meant for networks, .org meant for organizations, .edu reserved for educational institutions, .mil reserved for the US military, and .gov reserved for the US government. These are collectively called the original generic top-level domains (gTLDs).

In classic American fashion, the creators didn’t account for other countries at first. Since DNS was meant to be a global system, country-specific top-level domains were added. It was decided that the simplest way to accomplish this was to follow ISO 3166-1 alpha-2, a standard for 2-character country codes created by the International Organization for Standardization (this also avoided the problem of deciding which “countries” are countries, which is it’s own complicated subject). This means any two-letter top-level domain is managed by a country or territory. Of course, the United States had to start first with .us in February of 1985, but other countries quickly followed. These are now referred to as country-code top-level domains (ccTLDs).

Some countries benefitted quite a bit from these top-level domains. For example, .tv is for the island of Tuvalu, and .tv domain registrations makes up an appreciable portion of the government’s revenue. Similarly, .io is for the British Indian Ocean Territory, and .io domains are (or at least used to be) quite popular. As of late, Anguilla has been profiting off of .ai domains.

Now, every country is free to manage their own top-level domain as they see fit. While many smaller countries don’t want to look a gift horse in the mouth, some countries impose restrictions on their domains. For example, .us domains are limited to US citizens, residents, organizations, corporations, or some other presence in the United States. .it domains are similarly restricted to Italian citizens, residents, or companies. Monaco goes even further, only allowing companies with a trademark registered in Monaco to claim a .mc domain.

This intermingling of the digital and physical world introduces problems at times:

  • Despite the collapse of the Soviet Union, .su domains are still active and available for purchase.
  • .ly domains are managed by Libya. In 2010, the country revoked vb.ly for being associated with adult content.
  • Similarly, .af domains are managed by Afghanistan. The Taliban revoked queer.af in 2024.
  • .ac is currently for Ascension Island which was being considered for the ISO standard at the time of creation but ultimately never made the cut.
  • .cs was for Czechoslovakia, but after the country split into the Czech Republic and Slovakia, the top-level domain was deleted and .cz and .sk were created to replace it.
  • Despite not being a country, the European Union has the .eu top-level domain. After Brexit, UK residents who owned .eu domains were forced to give them up.

In 1998, the Internet Corporation for Assigned Names and Numbers (ICANN) was created to manage the global DNS system. In 2000, ICANN decided there were not enough generic top-level domains and announced seven new ones:

  • .aero
  • .biz
  • .coop
  • .info
  • .museum
  • .name
  • .pro

Since 2000, there were several more rounds of new gTLDs. However in 2012, ICANN began accepting applications for new gTLDs from companies. With a compelling enough pitch, and a nice pile of cash, you too could have your own top-level domain. This has created an explosion in top-level domains, with examples including .bridgestone (yes, the tire company), .irish, .zip, .mint and more. At the time of writing, there are over 1,500 top-level domains.

Software

You likely know that your computer takes a domain name and turns it into an IP address. But how exactly does it do that? Well, your computer asks a DNS server, such as 1.1.1.1, 8.8.8.8 or one that your ISP provides. But (ignoring caching) these servers don’t actually know the IP address of the domain you’re asking for. Instead, they have to ask the Root Name Servers.

The Root Name Servers bootstrap the global DNS system. There are 13 of them, named A through M, run by different organizations, such as NASA, University of Maryland, ICANN, and others. They have their own second-level domain, root-servers.net. The IP addresses of these servers are well-known and hardcoded into just about every piece of DNS software (so that you don’t have a cyclical problem of trying to resolve a.root-servers.net).

So, the DNS server talks to a randomly selected Root Name Server. But the Root Name Server doesn’t know the IP address of every domain in the world. Instead, they know what server to talk to for each top-level domain. Again, let’s use this site, blog.nathanv.me, as an example:

 1$ dig @a.root-servers.net blog.nathanv.me
 2
 3; <<>> DiG 9.18.18-0ubuntu0.22.04.2-Ubuntu <<>> @a.root-servers.net blog.nathanv.me
 4; (2 servers found)
 5;; global options: +cmd
 6;; Got answer:
 7;; ->>HEADER<<- opcode: QUERY, status: NOERROR, id: 61755
 8;; flags: qr rd; QUERY: 1, ANSWER: 0, AUTHORITY: 5, ADDITIONAL: 11
 9;; WARNING: recursion requested but not available
10
11;; OPT PSEUDOSECTION:
12; EDNS: version: 0, flags:; udp: 4096
13;; QUESTION SECTION:
14;blog.nathanv.me.               IN      A
15
16;; AUTHORITY SECTION:
17me.                     172800  IN      NS      b0.nic.me.
18me.                     172800  IN      NS      a0.nic.me.
19me.                     172800  IN      NS      c0.nic.me.
20me.                     172800  IN      NS      a2.nic.me.
21me.                     172800  IN      NS      b2.nic.me.
22
23;; ADDITIONAL SECTION:
24b0.nic.me.              172800  IN      A       199.253.60.1
25b0.nic.me.              172800  IN      AAAA    2001:500:54::1
26a0.nic.me.              172800  IN      A       199.253.59.1
27a0.nic.me.              172800  IN      AAAA    2001:500:53::1
28c0.nic.me.              172800  IN      A       199.253.61.1
29c0.nic.me.              172800  IN      AAAA    2001:500:55::1
30a2.nic.me.              172800  IN      A       199.249.119.1
31a2.nic.me.              172800  IN      AAAA    2001:500:47::1
32b2.nic.me.              172800  IN      A       199.249.127.1
33b2.nic.me.              172800  IN      AAAA    2001:500:4f::1
34
35;; Query time: 50 msec
36;; SERVER: 198.41.0.4#53(a.root-servers.net) (UDP)
37;; WHEN: Mon May 06 20:12:04 CDT 2024
38;; MSG SIZE  rcvd: 353

We can see here that we asked a Root Name Server about blog.nathanv.me, and it didn’t give us the IP address, but instead tells us that we need to talk to one of b0.nic.me, a0.nic.me, c0.nic.me, a2.nic.me, or b2.nic.me in order to get the next level of the domain, nathanv.me. It also helpfully provides the IP addresses of these servers so we don’t have to figure that out as well and get stuck in a loop.

Now let’s ask b0.nic.me:

 1$ dig @b0.nic.me blog.nathanv.me
 2
 3; <<>> DiG 9.18.18-0ubuntu0.22.04.2-Ubuntu <<>> @b0.nic.me blog.nathanv.me
 4; (2 servers found)
 5;; global options: +cmd
 6;; Got answer:
 7;; ->>HEADER<<- opcode: QUERY, status: NOERROR, id: 1860
 8;; flags: qr rd; QUERY: 1, ANSWER: 0, AUTHORITY: 2, ADDITIONAL: 1
 9;; WARNING: recursion requested but not available
10
11;; OPT PSEUDOSECTION:
12; EDNS: version: 0, flags:; udp: 1232
13;; QUESTION SECTION:
14;blog.nathanv.me.               IN      A
15
16;; AUTHORITY SECTION:
17nathanv.me.             3600    IN      NS      terin.ns.cloudflare.com.
18nathanv.me.             3600    IN      NS      deb.ns.cloudflare.com.
19
20;; Query time: 80 msec
21;; SERVER: 199.253.60.1#53(b0.nic.me) (UDP)
22;; WHEN: Mon May 06 20:15:47 CDT 2024
23;; MSG SIZE  rcvd: 99

Again, we can see that the name server b0.nic.me still doesn’t know the IP address of blog.nathanv.me but it does know who to talk to next, terin.ns.cloudflare.com or deb.ns.cloudflare.com. These are the name servers for the domain nathanv.me. Usually these are provided by your domain registrar, or in my case, Cloudflare. Finally, we can ask terin.ns.cloudflare.com for the IP address of blog.nathanv.me:

 1$ dig @deb.ns.cloudflare.com blog.nathanv.me
 2
 3; <<>> DiG 9.18.18-0ubuntu0.22.04.2-Ubuntu <<>> @deb.ns.cloudflare.com blog.nathanv.me
 4; (6 servers found)
 5;; global options: +cmd
 6;; Got answer:
 7;; ->>HEADER<<- opcode: QUERY, status: NOERROR, id: 11690
 8;; flags: qr aa rd; QUERY: 1, ANSWER: 2, AUTHORITY: 0, ADDITIONAL: 1
 9;; WARNING: recursion requested but not available
10
11;; OPT PSEUDOSECTION:
12; EDNS: version: 0, flags:; udp: 1232
13;; QUESTION SECTION:
14;blog.nathanv.me.               IN      A
15
16;; ANSWER SECTION:
17blog.nathanv.me.        300     IN      A       104.21.52.60
18blog.nathanv.me.        300     IN      A       172.67.195.246
19
20;; Query time: 30 msec
21;; SERVER: 108.162.192.92#53(deb.ns.cloudflare.com) (UDP)
22;; WHEN: Mon May 06 20:17:41 CDT 2024
23;; MSG SIZE  rcvd: 76

At last, we have learned that the IP address for blog.nathanv.me is either 104.21.52.60 or 172.67.195.246. A DNS server that performs these actions is called a “recursive resolver” as it has to recursively figure out who to ask for each part of the domain name.

You may be wondering, “Who do these Root Name Servers think they are? There’s nothing special giving them their power other than collective agreement. I want my own DNS root!”

Bender from Futurama saying 'We'll make our own DNS root with blackjack and hookers'

Well, you wouldn’t be the first. There are multiple groups that have created alternate DNS roots with their own Root Name Servers. Much like cryptocurrency trying to displace the US dollar, none of them have gained any widespread adoption.

Applications of DNS

While the above was a simple example of looking for the IP address of a domain name, there’s a lot you can do with DNS. For example, you can use it for load balancing. If you have multiple servers to run your application, you can configure your DNS server to randomly return a different IP address each time. Additionally, one of the most popular uses of DNS for consumer use is ad-blocking. With a server like Pi-Hole, you can run a DNS server that lies and pretends that domains that are known to serve ads don’t exist. Projects like DNS Toys exist that can provide useful information over the DNS protocol.

DNS can also be used for nefarious purposes. For example, you can use DNS for data exfiltration. Imagine making a DNS request for abcdefghijklmnopqrstuvwxyz.example.com. Even though this may not be a real domain, the example.com nameserver can log this request. Assuming you control the example.com nameserver, you can later view these requests to non-existent domains. Replace abcdefghijklmnopqrstuvwxyz with sensitive information like credentials or file contents, and you can easily get data out of a network in a way that is hard to detect and unlikely to be blocked.

Additionally, DNS amplification attacks can be a problem. Basically, an attacker sends a DNS request to a server and spoofs the IP address that the response should be sent to. As you can see in the dig commands above, the data size of the query is much smaller than the size of the response, so by sending lots of small queries to a large public DNS server, an attacker can “amplify” the volume of data they are sending and overwhelm their target.

Conclusion

Hopefully you learned something out of this. Wikipedia has lots of information about the history of DNS and all the weird edge cases that have come up over the years. I also highly recommend this video by Nill:

Other weird DNS facts:

  • .nato was created for NATO, but NATO quickly transitioned to using nato.int and it was deleted shortly after, basically unused.
  • A lot of people got very upset when Google created the .dev top-level domain as they were using it for development purposes. RFC 2606 reserves .example, .invalid, .localhost, and .test for this purpose, so they were playing with fire to begin with. .local and .onion have also been added to this list. While .home and .corp are not officially reserved, they are in pratice as ICANN has rejected proposals to register them.
  • A lot of people also got upset when Google created the .zip top-level domain as they feared it would be used to spread malware with applications like Twitter that recognize URLs without a proceeding http:// or https://.
  • The email address dot@dotat.at is my favorite domain hack (read it aloud if you don’t understand it).
  • Antarctica has it’s own top-level domain, .aq.
  • .edu domains used to have fewer restrictions than they do today. For example, merit.edu was registered and is still active despite not actually being an accredited educational institution. Most of these domains have been grandfathered in.
  • In definace of God and man and all things holy, certain top-level domains allow emojis. See: https://mailoji.com/

Further Reading

Footnotes

  1. Some usages of domain names do write the segments left-to-right. A notable example of this are Android package names. This site as an Android package would be me.nathanv.blog. Humans tend to find this less intuitive, but it makes it easier for computers to parse. ↩︎
